Description
Technical Data
- Predetermined positioning of the cutting angles at -45°/90°/45 with blocking of the rotating bench by means of high precision pins
- Possibility to perform cuts at any intermediate degree from 80° to -80° with mechanical stop on the rotating bench
- Full protection of the saw blade by means of safety cover with manual closing (CE version)
- Easy and light rising of the saw blade by a manual lever (with 2 buttons on “A” version)
- Possibility to perform ripping operations from 0 to 60mm with the rear moveable fence (optional)
- 1.1Kw (1.5HP) 3 phase motor – 2800 r.p.m.
- Max. saw blade Ø 400mm
- Saw blade shaft Ø 30mm
- Working pressure 7 bar
- Overall dimensions 64x78x125cm
- Weight 120kg
Standard Equipment
- Waste suction hood
- Vertical pneumatic clamps
- Automatic lubrication by the nebuliser
- Air filter (Only on CE version)
- Air gun
- Service spanners
Optional Features
- Moveable trimming rear fence
- Horizontal clamps
- Single phase motor
- Horizontal clamp
