Description
Technical Data
- Full protection of the milling group by the safety cover with manual closing
- Quick and easy pneumatic change of the cutter block shaft
- Possibility to perform end milling operations at any degree from 90° to 45° both right and left side
- 1.1Kw (1.5HP) 3 phase motor – 2800 rpm
- Cutter block shaft Ø 32mm
- Horizontal shaft stroke 290mm
- Mex. cutter block Ø 120mm
- Working pressure 7 bar
- Overall dimensions 61x82x123cm
- Weight 95kg
Standard Equipment
- Nr 1 cutter block shaft c/w spacer rings with different tickness
- Shaft quick release device
- Tilting fence for off-square milling operation at 45°/90°/-45°
- Depth end stop with 6 presetting positions
- Vertical and horizontal pneumatic clamps with variable positioning
- Automatic lubrication by nebuliser
- Shafts holder device
- Air filter
- Air gun
- Service Spanners
Optional Features
- Supplementary cutter block shaft
- Single phase motor
