Description

Technical Data

Manual down stroking of the head by means of ergonomic safety lever
Blade protection cover with automatic closing by means of lever
Head rotation on its own axis at -45° / 45° with mechanical locking system
Manual locking system on working bench at any intermediate degree
Rotating working bench
Sawblade Ø 350 mm
Sawblade shaft Ø 30 mm
1,8 Kw (2,5 Hp) 3 phase self-braking motor – 3000 r.p.m.
Working pressure 7 bar
Overall dimensions 70x70x132 cm
Weight 75 kg.

Standard Equipment

Horizontal pneumatic clamps
Automatic lubrication by means of nebulizer
Suction hood connection

Optional

Air gun
Single phase motor
