Radial sliding of the sawing group
Semi automatic feeding of the sawing carriage by means of buttons (manual “M” version)
Protection of the sawblade by means of adjustable safety guard
Manual tilting of the head with indexed reference points at -45°/90°/45°
Manual tilting and locking of the head up to 22,5° (R-L)
Easy and fast setting/reading of the intermediate degrees on big size goniometer
Sawblade max. Ø 400 mm
Sawblade shaft Ø 30 mm
1,5 Kw (2 HP) 3 phase motor – 2800 r.p.m.
Working pressure 7 bar
Overall dimensions 69x95x140 cm
Weight 220 kg
Standard Equipment
Horizontal pneumatic clamps
Automatic lubrication by means of nebulizer
Interchangeable aluminium support/base on working bench
Air filter
Air gun
Service Spanners
Optional
Single phase motor
