Description
Technical Data
Electro-welded and stabilized basement
Machine equipped with electronic positioner c/w 10″ color monitor and touch screen system
USB port to store/upload cutting lists
Full protection of the sawblades by means of safety hoods with automatic closing
Moving of right head, equipped with brushless motor, on tempered and rectified rack and pinion
Reading of the displacement by means of encoder
Vertical radial sliding of the sawing group on linear guides and balls recirculating skids with oleo-pneumatic cylinder
Pneumatic tilting of the sawing group from 90 ° to -45° with possibility of manual setting of intermediate degrees
Heads manual rotation with pneumatic index at 45°/90°/-45°
Machine predisposed for chippings suction with connections Ø 120 mm
3 Kw (4 HP) 3 phase motors – 2800 r.p.m.
Cutting lengths 4000/5000 mm
Max. Sawblade Ø 550 mm
Sawblade shaft Ø 30 mm
Working pressure 7 Bar
Overall dimensions 575/675x153x196 cm
Weight 2230/2370 Kg
Standard Equipment
Nr. 2 horizontal pneumatic clamps
Nr. 2 vertical pneumatic clamps
Nr. 2 Sawblades Ø 550mm
USB flash drive
Automatic lubrication by means of nebulizer
In feed roller conveyor with reduced cut device
Air filter
Air gun
Service spanners
Optionals
Standard bar label printer
Manual central support
Pneumatic central support
Over size cut device
Trim cut device
