Description
Technical Data
Radial sliding of the sawing group
Full protection of the sawblade by means of safety cover with manual closing
Automatic, pneumatic tilting of the head with indexed positions at -45°/90°/45°
Possibility to perform, cuts at any intermediate degrees from 30° left to 30° right, with mechanical end stop
Outfeed of the sawblade by means of oleo-pneumatic cylinder
Idro-pneumatic external adjustment of the saw blade feeding
Possibility to mount sawblades with Ø 500 – 530 – 550 mm
Sawblade shaft Ø 30 mm
Overall dimensions 76x135x156 cm
Weight 330 kg
Standard Equipment
TCT saw Blade Ø 500 mm
Nr 2 horizontal pneumatic clamps
Automatic lubrication means of nebulizer
Interchangeable aluminium support/base on working bench
Air filter
Air gun
Service spanners
Optional
Single phase motor
Vertical clamping kit
